How to choose the right hose reel for your needs
Which parameters determine the right choice?
When choosing an industrial hose reel, the first question seems simple: how many meters of hose does it need to accommodate? In reality, hose length is only one of the factors to consider. To select the most suitable hose reel, you must also take into account the characteristics of the system, the fluid being handled, and the operating pressure and temperature conditions. The right choice therefore comes from evaluating a combination of data.
For example, a model suitable for potable water may not be suitable for steam, chemical detergents, or marine environments. Likewise, a reel drum with sufficient capacity may not comply with the hose’s minimum bend radius or provide the required flow passage.
This article will help you understand the main aspects to evaluate before requesting a hose reel. Having the right information at hand will make it easier to identify a configuration that matches your application and to discuss your requirements effectively with the supplier.
The fluid is the first parameter to define
The first question to ask when selecting the right hose reel is: what fluid will the hose reel handle?
Water, compressed air, steam, fuels, chemicals, and food-grade liquids all have different requirements. Not only does the working environment change, but so do the materials that come into contact with the fluid.
Other factors that influence the selection include:
- Product concentration
- Temperature
- Operating method
- Cleaning frequency
For potable water applications or food contact, it is also necessary to verify the applicable regulatory requirements and the documentation relating to the specific configuration.
Stainless steel may be suitable for humid environments or applications involving frequent washdowns, but it is not a universal guarantee against corrosion. In the presence of chlorides, saltwater, or aggressive substances, it is also necessary to evaluate the stainless steel grade and the compatibility of the other components.
Manual, automatic or motorized hose reel?
The choice of rewind technology depends primarily on how the hose reel will be used.
- If the application is occasional and the hose length is limited, a manual hose reel is certainly the most practical and functional solution. The operator rewinds the hose using a hand crank, keeping the system simple and easy to use.
- For frequent use and medium to long hose lengths, an automatic hose reel is generally the ideal solution, as the internal spring assists with hose retraction.
- For long hose lengths, heavy hoses, or systems requiring a higher level of automation, a motorized hose reel is preferable. Hydraulic, pneumatic, and electric drive systems meet different requirements and should be selected according to the available power source, the torque required, and the working environment.
Pressure and flow rate are two different characteristics
Before continuing with this guide to choosing the right hose reel, it is important to clarify the difference between pressure and flow rate:
- Pressure is the force exerted by the fluid against the walls of the hose.
- Flow rate is the quantity of fluid passing through the system within a given period of time.
A system may be designed for high pressure while still being unable to support the flow rate actually required. To avoid such problems, it is necessary to consider all the factors that influence how the fluid flows through the system:
- Hose internal diameter
- Swivel joint
- Fittings
- Bends
- Hose length
If even one of these elements is undersized, it can become a critical point and reduce system performance.
But what happens when a hose reel is operated at a pressure lower than the one it was designed for? In this case, the hose reel will continue to function correctly, but it will be larger, heavier, and more expensive than necessary. For this reason, this solution is generally not recommended.
The opposite situation is different: using a hose reel designed for low-pressure applications beyond its rated pressure can compromise safety and must be strictly avoided.
It is therefore not enough to choose the product that supports the highest pressure value. The solution must be consistent with the requirements of the entire system.
Hose, drum and reeling capacity
The capacity of a hose reel depends both on the dimensions of the drum and on the characteristics of the hose. In addition to the required hose length, it is necessary to know:
- The internal and external diameters required for fluid passage
- The hose weight
- The minimum bend radius
However, two hoses with the same nominal size may have different overall dimensions due to materials, reinforcements, and wall thicknesses. If the hose occupies more space than expected, the reel's actual capacity decreases.
Conversely, a hose wound on a drum with a diameter that is too small may be subjected to unnecessary stress over time. The drum core diameter must therefore be compatible with the minimum bend radius specified by the hose manufacturer.
How does the working environment influence configuration selection?
The same hose reel can be used in different working environments, but each environment requires specific considerations: humidity, frequent washdowns, saltwater exposure, corrosive substances, high pressure, and more.
The material of the main structure is only one part of the selection process. In addition to the structure, it is important to evaluate:
- Swivel joint
- Fasteners and bolts
- Seals
- Fittings
For motorized models, the drive system and electrical or pneumatic components must also be assessed.
For certain applications, specific regulatory requirements also apply:
- ATEX and MINING ATEX: for use in potentially explosive atmospheres, a product with the appropriate marking and category for the designated zone and operating conditions must be selected. A stainless steel hose reel is not necessarily ATEX compliant. The hose, accessories, and equipotential bonding system must also be evaluated.
- MOCA: for food-contact applications, it is necessary to verify the suitability of all materials that come into contact with the product and to check the declaration of conformity applicable to the specific configuration and intended operating conditions. This is not a generic certification valid for every food product or application.
The mounting orientation and installation point also affect usability. It is therefore useful to specify whether the hose reel will be mounted on a wall, on a ceiling, on the floor or on a machine.
What to know before requesting a quotation
To receive a proposal that is truly suited to your needs, it is important to have the following fundamental information available:
Type of fluid to be handled
Operating pressure and temperature
Hose length and diameter
Preferred drive technology (manual, automatic spring rewind, or motorized)
Working environment
Ramex provides a practical configurator designed to guide you simply and intuitively toward the solution that best suits your requirements.
For special applications, customized products, or questions regarding hose reel selection, you can contact our team directly by writing to ramex@ramex.it.
Frequently Asked Questions
How do I know which hose reel I need?
Start with five key pieces of information: the fluid, operating pressure, hose length, hose diameter, and preferred drive technology. With this information, it is possible to identify the correct configuration. The website configurator will help guide you through the process.
Can I use the same hose reel for a different fluid?
Only after verifying that the hose reel is compatible with the characteristics of the fluid and the working environment.
What is the difference between a manual, automatic and motorized hose reel?
A manual hose reel is rewound using a hand crank and is the most economical solution. An automatic spring-driven hose reel rewinds the hose automatically and is the most commonly used compromise between convenience and cost. A motorized hose reel (hydraulic, pneumatic, or electric) is designed for long hose lengths or intensive operating cycles and significantly reduces operator effort.
Can I use a 400 bar hose reel at a lower pressure?
Yes, it will work correctly, but it will be heavier, bulkier, and more expensive than necessary. The opposite is not allowed: using a low-pressure hose reel beyond its rated pressure is dangerous.
Why is my flow rate lower than expected?
In most cases, because the internal passage diameter is insufficient or because pressure losses are caused by hose length, bends, and fittings. Flow rate depends on the available passage area, not just on pressure.
Is stainless steel always the best choice?
Not necessarily. Stainless steel, available in both 304 and 316 grades, may be the right choice in many applications, but the fluid type and operating environment must always be carefully evaluated.
When is an ATEX hose reel required?
When it is intended for use in areas with potentially explosive atmospheres (ATEX zones). Suitable materials, grounding, and certified components are required. Being made of stainless steel does not automatically mean a hose reel is ATEX compliant.
